NEWLAND MACHINE TOOL – NVT2000

VTC details:

  • Max turning diameter and swing, mm (in) – 2235 (88) (92” close to the chuck)
  • Chuck diameter, mm (in) – 1600 (63)
  • Max turning height, mm (in) – 1600 (63)
  • Max table load capacity, kg (lb.) – 20000 (44000)
  • Table Drive: Max speed – RPM450
  • Power, kW (HP) – 60 (80)
  • Torque, Nm (ft lbs.) – 30000 (22125)
  • Ram: Ram size, mm (in) – 254 x 254 (10 x 10)
  • Max cutting force, N (lb.) – 40000 (8990)
  • Travels: Ram (Z-axis), mm (in) – 1250 (49)
  • Crossrail travel, mm (in) – 1000 (39.370)
  • Crossrail fixed positons pitch, mm (in) – 200 (7.874)
  • Number of crossrail positions. – 6
  • X and Z rapid travers, mm/min (ipm) – 12000 (472)
  • X and Z max feed rates, mm/min (ipm) – 5000 (200)

NEWLAND MACHINE TOOL – NVT2000

PHONE: 770-222-4918
Our capabilities range from very small to large parts (up to 30,000 lbs). Examples: Tool & dies, fixtures for manufacturing, hydroform blocks, nuclear/ hydro power generation, proto types, medical parts, packaging equipment, etc….
•Hydro/Nuclear Power Generation •Medical •Automotive •Aerospace •Communications •Robotics •Marine •Equipment manufacturing •Pipeline •Pulp and Paper •Plastics

A PLEDGE TO OUR CUSTOMERS:

3D-Machine will machine parts to meet customers exacting specifications. We understand the requirements and are focused on providing our customers with the highest quality at competitive prices, on schedule.
